Components
INE-4KW-HY
INE-5KW-HY
INE-6KW-HY
INE-8KW-HY
INE-10KW-HY
Hybrid Inverter
SPH 4000TL3 BH
SPH 5000TL3 BH
SPH 6000TL3 BH
SPH 8000TL3 BH
SPH 10000TL3 BH
2.4KWH Battery
3 Piece
3 Piece
3 Piece
4 Piece
5 Piece
DC Cable 4mm2
200 Meter
200 Meter
200 Meter
300 Meter
300 Meter
MC4 Connector
10 Set
10 Set
10 Set
15 Set
15 Set
Mounting System
Metal Roof/Tile Roof/Tilt Mounting/Ground Mounting
PV Tools
1 Set
* Above information is for reference only, specific configuration is depend on customer's requirement and in accordance with the actual order.
The best of all worlds - this system comprises solar power with battery backup and all excess power generated by the solar panels is returned to the grid. Smart inverters can be programmed to use battery power during municipality peak tariff times. In the ultimate hybrid configuration, power can be generated by solar panels, wind turbines, diesel generator or mains, alone or in any combination.
Tolerance: 0~5W
Application Class: Class A
Maximum System Voltage: 1000VDC/1500VDC
Operating Temperature: -40℃~+85℃
Maximum Series Fuse Rating: 20A
Warranty: 12 years quality warranty
Max. PV Input Power : 4/5/6/7/8/9/10KW
Mac.DC voltage:1000V
No. of MPP trackers:2
AC voltage range : 230V/400V(310~476V)
Battery voltage range:100~550V
Display:LCD+LED
Warranty: 5-10 years
Nominal Capacity:50ah
Nominal Voltage:48V
Nominal Battery Energy:2.4KWh
Protection Level:IP20
Communication:CAN / RS485 / DRY CONTACT
Certification & Safety
Standard:TUV/CE/EN62619/IEC62040/UN38.3/CEC
Accredited
Real-Time Display
Years of Historical Data
Functionality Control
View Financial Savings
Plug & Play Installation
Email System Alerts
Model Type: Roof/Ground
Material: Al6005 & SUS304/316 & HDG
Mid & End Clamp: 35,40,45,50mm
Application: Residential/Commercial/Industrial
Packing: Wooden Box and Wrapping Film
Warranty: 10 Years Warranty
Model Type: PV1-F
Cross Section: 4mm2, 6mm2, 10mm2
Rated Voltage: AC 600/1000V, DC 1800V
Color: Black & Red
Warranty: 10 years quality warranty
Life Span: At least 25 years
PV Connector Crimper
Wire Cable Cutter & Stripper
PV Connector Spanner
Cross Screwdriver
