Components
 INE-10KW-OFF
 INE-15KW-OFF
 INE-20KW-OFF
 INE-25KW-OFF
 INE-30KW-OFF
320W Mono Solar Panel
 28 Piece
 56 Piece
 64 Piece
 84 Piece
 96 Piece
Off Grid Inverter
 10KW
 15KW
 20KW
 25KW
 30KW
PWM Controller
 220V 50A
 220V 100A
 220V 100A
 220V 150A
 220V 150A
Combiner Box
 4 in 1 out
 2*4in 1 out
 2*4in 1 out
 3*4in 1 out
 3*4in 1 out
12V 200AH Battery
 18 Piece
 18 Piece
 36 Piece
 36 Piece
 36 Piece
PV cable
 300 Meters
 400 Meters
 600 Meters
 600 Meters
 600 Meters
Battery Cable
 20 Piece
 20 Piece
 38 Piece
 38 Piece
 38 Piece
MC4 Connector
 10 Set
 12 Set
 15 Set
 20 Set
 30 Set
PV Tools
 1 Set
 1 Set
 1 Set
 1 Set
 1 Set
Mounting System
 Metal Roof/Tile Roof/Tilt Mounting/Ground Mounting

* Above information is for reference only, specific configuration is depend on customer's requirement and in accordance with the actual order.








Mono Solar Panels

Rated Maximum Power: 380W (INE-380-72M)
Maximum Power Voltage: 36.97V
Maximum Power Current: 7.79A
Open Circuit Voltage: 44.69V
Short Circuit Current: 8.26A
Dimensions:1956X992X40mm
Weight:22.5 kg

Off Grid Inverter

Rate power:10/15/20/30KW
Rated voltage(VDC): 220
Input Voltage Range(Vac):220±15%/110±15%
AC Output Voltage :220VAC±1%;110VAC±1%
Inverter Efficiency:≧90%
Communication:RS485/GPRS(Optional)

PWM Controller (MPPT optional)

Rated Voltage (VDC):220
Charging Current (A): 50/100/150/200
Maximum input power:44000W
Charge loop drop:≦0.5V
Controller efficiency : ﹥99%
Dimension(WxHxD)mm : 432*280*131.6
Weight(Kg) : 7.8

PV COMBINER BOX

Color:White/Grey
Product name:PV combiner box
Connection:2,4,6,8,10,12,14,16,20,24 Ways
Character:With monitor,thunder-proof,water-proof
Rated working current:UP TO 250A
Protection Level:IP65
BOX Material:Iron Steel

Lead Acid GEL Battery

Cells Per Unit:6
Nominal Voltage(Vdc): 12
Nominal Capacity(AH): 200
Depth of Discharge: 70%
Design Life: 10-15 years
Capacity: 200Ah@10hr-rate to 1.80V per cell
@25°C

PV Mounting System

Design Standard：AS/NZS 1170,DIN 1055,
JIS C 8955
Material: AL 6005-T5,SUS 304,Q235B
Fastener: SUS304
Small Components:Al6005-T5(Anodized)
Color:Silver or Customized
Warranty:10-Year Warranty

PV Cable & MC4 Connector

Cross Section: 4mm2, 6mm2 Optional
Rated Voltage:600VDC(UL)/1000VDC(TUV)
Rated Current: 55A,70A
Colors: Black For STD, Red Optional.

PV Tools

Wire Cable Cutter and Stripper,
MC3 MC4 Crimping Tools
MC4 Connectors Assembly
Disassembly Tool
